Resources

Material Information Card TP 005 covering MagneForm® F-120, MagneBond® FX-120, and FX2-120 enamelled winding wire products.

Material Information Card TP 006 covering MagneBond® AB-220 enamelled winding wire product.

Review the Enamel Terms and Conditions of Sale for North America.

EnduroTemp® 260+ uses Essex proprietary Polyimide formulation combined with a proprietary self-lubricating top coat. This product not only complies but clearly exceeds NEMA MW 16-C/MW 20-C with a Thermal Endurance of 265°C per ASTM D2307. The unique combination also provides high abrasion resistance to reduce damage in winding & assembly process. The enamel is specially formulated to provide outstanding resistance to Partial Discharge and Corona effect making it suitable for all the above key applications. This product exhibits high flexibility and property retention maintaining product performance even after the winding operation.

EnduroTemp® 260+ uses Essex proprietary Polyimide formulation combined with a proprietary self-lubricating top coat. This product not only complies but clearly exceeds NEMA MW 16 with a Thermal Endurance of 265°C per ASTM D2307. The unique combination also provides high abrasion resistance to reduce damage in winding & assembly process. The enamel is specially formulated to provide outstanding resistance to Partial Discharge and Corona effect making it suitable for all the above key applications. This product exhibits high flexibility and property retention maintaining product performance even after the winding operation.

A comprehensive reference guide that provides essential technical information, formulas, guidelines, and best practices.

Environmental Disclosure for the Magnet Wire Plant in Suzhou, China, detailing hazardous waste pollution prevention and control measures.

DLGS 116-2020 environmental label packaging compliance at our Quattordio, Italy magnet wire plant for responsible material practices.

Essex Solutions is committed to reducing the environmental impacts of our activities, products and services to preserve and protect the natural environment including the air, water, land and other natural resources.

Formvar is a synthetic film insulation containing Polyvinyl Acetal and phenolic resins.

Formvar is a synthetic film insulation containing Polyvinyl Acetal and phenolic resins.

Formvar-EXTRA is a synthetic film insulation containing modified polyvinyl acetal and phenolic resins. Formvar-EXTRA is based on the same enamel formulation that has been in use for over 50 years. Its 141°C Thermal Index is the highest in the market for aluminum products meeting MW 86 / MW 87. It also passes 220°C heat shock as well as 300°C thermoplastic flow. It is a non-solderable product and must be mechanically stripped before soldering, or terminated by means of insulation piercing terminals.
